Digital Electronics and Design with VHDL offers a friendly presentation of the fundamental principles and practices of modern digital design. Unlike any other book in this field, transistor-level implementations are also included, which allow the readers to gain a solid understanding of a circuit's real potential and limitations, and to develop a realistic perspective on the practical design of actual integrated circuits. Coverage includes the largest selection available of digital circuits in all categories (combinational, sequential, logical, or arithmetic); and detailed digital design techniques, with a thorough discussion on state-machine modeling for the analysis and design of complex sequential systems. Key technologies used in modern circuits are also described, including Bipolar, MOS, ROM/RAM, and CPLD/FPGA chips, as well as codes and techniques used in data storage and transmission. Designs are illustrated by means of complete, realistic applications using VHDL, where the complete code, comments, and simulation results are included. This text is ideal for courses in Digital Design, Digital Logic, Digital Electronics, VLSI, and VHDL; and industry practitioners in digital electronics.
- Comprehensive coverage of fundamental digital concepts and principles, as well as complete, realistic, industry-standard designs
- Many circuits shown with internal details at the transistor-level, as in real integrated circuits
- Actual technologies used in state-of-the-art digital circuits presented in conjunction with fundamental concepts and principles
- Six chapters dedicated to VHDL-based techniques, with all VHDL-based designs synthesized onto CPLD/FPGA chips
Introduction; Binary representations; Binary arithmetic; First glance at digital circuits; Binary function analysis; Line codes; Error-detecting/correcting codes; Bipolar Transistors; Bipolar logic families; MOS transistors; MOS logic families; Combinational logic circuits; Combinational arithmetic circuits; Registers; Sequential subsystems; Finite state machines; Volatile memories; Non-volatile memories; Programmable logic devices (PLDs); VHDL summary; VHDL designs of combinational logic circuits; VHDL designs of combinational arithmetic circuits; VHDL designs of regular sequential circuits; VHDL designs of FSM-based sequential circuits; VHDL simulation with testbenches; Circuit simulation with Spice.
